LVL are wooden board that made of thin wood veneers glued together. First, a tree is rotary peeling by Wood veneer peeling machine for LVL plywood line in one long layer. After several processes, such as rolling out and drying, the long layer of wood veneer sheet will become firmer and less flexible. Afterwards, several layers of these sheets made by Wood veneer peeling machine for LVL plywood line are glued together under high pressure, to form one big wooden plank.
We offer a wide range of woodworking machinery for wood processed panels such as plywood, block board, and LVL to customers all over the world. These include plywood wood veneer peeling machine, including spindleless & spindle wood veneer peeling machine, wood debarker, wood veneer clipper, veneer stacker, plywood hot press machine, plywood cold press machine, wood veneer dryer and other related products.
DESCRIPTION | UNIT | BQ1813/G4GS-JDServo, Manual speed adjustment by inverter
|
Length of log | mm | 900-1400 |
Diameter of log | mm | 28-450 |
Length of blade | mm | 1500 |
Thickness of veneer | mm | 0.8-4.0 |
Width of cut veneer | mm | 500-1300 |
Linear speed of host machine | m/min | 40~80m/min |
Diameter of driving roller | mm | 102 |
Diameter of pressure bar roller | mm | 116 |
Diameter of rubber roller | mm | 140 |
Power of pressure barroller | kw | 11 |
Power of double roller | kw | 11 |
Power of feeding | kw | 11(servo) |
Power of shear | kw | 3 |
Power of output conveyor | kw | 1.5 |
Total power | kw | 37.5 |
Total weight | kg | 5500 |
Overall dimensions | mm | 3900*2500*1600 |
LVL are wooden board that made of thin wood veneers glued together. First, a tree is rotary peeling by Wood veneer peeling machine for LVL plywood line in one long layer. After several processes, such as rolling out and drying, the long layer of wood veneer sheet will become firmer and less flexible. Afterwards, several layers of these sheets made by Wood veneer peeling machine for LVL plywood line are glued together under high pressure, to form one big wooden plank.
We offer a wide range of woodworking machinery for wood processed panels such as plywood, block board, and LVL to customers all over the world. These include plywood wood veneer peeling machine, including spindleless & spindle wood veneer peeling machine, wood debarker, wood veneer clipper, veneer stacker, plywood hot press machine, plywood cold press machine, wood veneer dryer and other related products.
DESCRIPTION | UNIT | BQ1813/G4GS-JDServo, Manual speed adjustment by inverter
|
Length of log | mm | 900-1400 |
Diameter of log | mm | 28-450 |
Length of blade | mm | 1500 |
Thickness of veneer | mm | 0.8-4.0 |
Width of cut veneer | mm | 500-1300 |
Linear speed of host machine | m/min | 40~80m/min |
Diameter of driving roller | mm | 102 |
Diameter of pressure bar roller | mm | 116 |
Diameter of rubber roller | mm | 140 |
Power of pressure barroller | kw | 11 |
Power of double roller | kw | 11 |
Power of feeding | kw | 11(servo) |
Power of shear | kw | 3 |
Power of output conveyor | kw | 1.5 |
Total power | kw | 37.5 |
Total weight | kg | 5500 |
Overall dimensions | mm | 3900*2500*1600 |
