Wood Veneer Peeling Machine for LVL

Wood veneer peeling machine for LVL is generally used in the LVL plywood making.
Availability:
Quantity:

Machines For Laminated Veneer Lumber


LvL Plywood Making


Wood veneer peeling machine for LVL is generally used in the LVL plywood making. LVL is composite product manufactured from multiple layers of veneer sheets with a thickness of 2.5mm to 4.8mm.


LVL production


Typical veneer thickness for LVL production is 3.2mm. Wood veneer peeling machine for LVL is the most LVL plywood producing process. LVL are mainly used in construction and wood structures. LVL veneers are arranged in the same direction, and assemble along the longitudinal direction, so LVL have similar properties of solid lumber.


Fuzhou Mutian produces many kinds of plywood making and wood veneer peeling machine, including spindleless & spindle wood veneer peeling machine, log debarker, wood veneer clipper, veneer stacker, plywood hot press machine, plywood cold press machince, wood veneer dryer and other related products.


Veneer Peeling Machine


Specification


DESCRIPTION

UNIT

BQ1813/G4S-JServo

Length of log

mm

900-1400

Diameter of log

mm

28-450

Length of blade

mm

1500

Thickness of veneer

mm

0.8-4.0

Width of cut veneer

mm

500-1300

Linear speed of host machine

m/min

60m/min

Diameter of driving roller

mm

102

Diameter of pressure bar roller

mm

116

Diameter of rubber roller

mm

140

Power of pressure barroller

kw

11

Power of double roller

kw

11

Power of feeding

kw

11(servo)

Power of shear

kw

3

Power of output conveyor

kw

1.5

Total power

kw

37.5

Total weight

kg

5500

Overall dimensions

mm

3900*2500*1600


Images



Wood veneer peeling machine for LVLPlywood veneer peeling machine

Spindleless veneer rotary peeling machineveneer rotary peeling machineveneer peeling lathe
