Spindleless veneer peeling machine for Laminated veneer lumber

Spindleless Veneer Peeling Machine Manufacturers

Laminated Veneer Lumber

Laminated veneer lumber, more widely known as LVL, is an engineered wood product used in a wide range of building contruction applications. LVL is made of 2.5 to 4.8mm thick veneers bonded together with weather-resistant phenolic adhesive. Spindleless veneer peeling machine for Laminated veneer lumber is the machine to peel thick wood veneer. Then hot press machine laminate wood veneer together under precise conditions. LVL is twice as strong as steel in proportion to weight.

Plywood Wood Veneer Peeling Machine

Fuzhou Mutian produces many kinds of plywood wood veneer peeling machine, including spindleless & spindle wood veneer peeling machine, log debarker, wood veneer clipper, veneer stacker, plywood hot press machine, plywood cold press machince, wood veneer dryer and other related products.

Function

Peeling and cutting wood veneers from wood. The veneer width and length can be adjustable during plywood wood veneer peeling process.

Specification

DESCRIPTION	UNIT	BQ1813/G4GS-JDServo, Manual speed adjustment by inverter
Length of log	mm	900-1400
Diameter of log	mm	28-450
Length of blade	mm	1500
Thickness of veneer	mm	0.8-4.0
Width of cut veneer	mm	500-1300
Linear speed of host machine	m/min	40~80m/min
Diameter of driving roller	mm	102
Diameter of pressure bar roller	mm	116
Diameter of rubber roller	mm	140
Power of pressure barroller	kw	11
Power of double roller	kw	11
Power of feeding	kw	11(servo)
Power of shear	kw	3
Power of output conveyor	kw	1.5
Total power	kw	37.5
Total weight	kg	5500
Overall dimensions	mm	3900*2500*1600

Images
