Suitable Plywood machine roller veneer dryer has many positive impacts on veneer quality and plywood production. The Plywood machine roller veneer dryer is capable to handle veneer sheets peeled from hardwood and softwood. It can be installed on a flat floor.
This Plywood machine roller veneer dryer can less 80% operators for drying phases compared to natural drying processes.
Fuzhou Mutian offers several different Plywood machine roller veneer dryer which is suitable for different plywood production process. By choosing suitable Plywood machine roller veneer dryer, you will get high-quality, even flatness veneer sheet that are ready to be processed as plywood, LVL beams and other artificial panel.
DESCRIPTION | UNIT | Roller Veneer Dryer |
Density | Kg/m3 | 590 |
Veneer Thickness | mm | 1.5 |
Initial moisture content | / | 75% |
Final moisture content | / | 8-10% |
Heating media | / | Saturated steam or heat-transfer oil(working pressure 0.8Mpa) |
Working temperature | / | 160℃ |
Load ratio | / | 85% |
Working width | mm | 2800 |
Working decks | / | 3 |
Length of heating section | mm | 13*2000=26000 |
Length of cooling section | mm | 2*2000=4000 |
Roller Transmission speed | m/min | 1.5-15 |
Drying capacity | m3/h | 4.5 |
Effective hear consumption | kcal/h | 220 |
Motor installed capacity | kw | 183.5 |
Motor for transmission | kw | 7.5+11=18.5 |
Motor for ventilation | kw | 13*11=143 |
Motor for ventilation | kw | 4*5.5=22 |
Compressed air pressure | Mpa | 0.4-0.5 |
Compressed air consumption under free state | m3/min | 1.0 |
Total size (L*W*H)Excluded humiditu-dischargingand exhaust device | mm | 46850*5400*4300 |
Suitable Plywood machine roller veneer dryer has many positive impacts on veneer quality and plywood production. The Plywood machine roller veneer dryer is capable to handle veneer sheets peeled from hardwood and softwood. It can be installed on a flat floor.
This Plywood machine roller veneer dryer can less 80% operators for drying phases compared to natural drying processes.
Fuzhou Mutian offers several different Plywood machine roller veneer dryer which is suitable for different plywood production process. By choosing suitable Plywood machine roller veneer dryer, you will get high-quality, even flatness veneer sheet that are ready to be processed as plywood, LVL beams and other artificial panel.
DESCRIPTION | UNIT | Roller Veneer Dryer |
Density | Kg/m3 | 590 |
Veneer Thickness | mm | 1.5 |
Initial moisture content | / | 75% |
Final moisture content | / | 8-10% |
Heating media | / | Saturated steam or heat-transfer oil(working pressure 0.8Mpa) |
Working temperature | / | 160℃ |
Load ratio | / | 85% |
Working width | mm | 2800 |
Working decks | / | 3 |
Length of heating section | mm | 13*2000=26000 |
Length of cooling section | mm | 2*2000=4000 |
Roller Transmission speed | m/min | 1.5-15 |
Drying capacity | m3/h | 4.5 |
Effective hear consumption | kcal/h | 220 |
Motor installed capacity | kw | 183.5 |
Motor for transmission | kw | 7.5+11=18.5 |
Motor for ventilation | kw | 13*11=143 |
Motor for ventilation | kw | 4*5.5=22 |
Compressed air pressure | Mpa | 0.4-0.5 |
Compressed air consumption under free state | m3/min | 1.0 |
Total size (L*W*H)Excluded humiditu-dischargingand exhaust device | mm | 46850*5400*4300 |
