Plywood core veneer dryer is one of the most important phases of veneer production. The main purpose of the Plywood core veneer dryer is to produce high-quality dried veneer sheets with the highest efficiency. Plywood veneer dryer machine removes water from the wood veneer and decrease moisture by using hot and humid air.
Fuzhou Mutian offers several different Plywood core veneer dryer which is suitable for different plywood production process. By choosing suitable Plywood core veneer dryer, you will get high-quality, even flatness veneer sheet that are ready to be processed as plywood, LVL beams and other artificial panel.
Product Specification
DESCRIPTION | UNIT | |
Unit weight | Kg/m3 | 590 |
Veneer Thickness | mm | 1.7 |
Initial moisture content | / | 70% |
Final moisture content | / | 8-10% |
Heating media | / | Heat-transfer oil |
Working temperature | / | 170℃ |
Load ratio | / | 85% |
Working width | mm | 2650mm for mesh belt 2800mm for roller |
Working decks | / | 4 decks The upper one is mesh belt The bottom three is roller |
Length of heating section | mm | 11*2000=22000 |
Length of cooling section | mm | 2*2000=4000 |
Roller Transmission speed | m/min | 1.5-15 |
Mesh belt transmission speed | m/min | 2.5-25 |
Drying capacity | m3/h | 5.0 |
Effective hear consumption | 100 thousand kcal/h | 250 |
Motor installed capacity | kw | 284 |
Motor for transmission | kw | 11*4=44 |
Motor for ventilation | kw | 15*11=165 |
Motor for ventilation | kw | 4*5.5=22 |
Compressed air pressure | Mpa | 0.4-0.5 |
Compressed air consumption under free state | m3/min | 0.8 |
Total size (L*W*H) Excluded humidity-discharging and exhaust device | mm | 44880*5385*5050 |
