The electrically operated Log spindleless veneer peeling machine peels high-quality veneer from hardwood and softwood. It is especially for India and Indonesia Sengon, Eucalyptus and Rubber wood and small diameter species. The modern features of this Log spindleless veneer peeling machine improve the yield and effectiveness of plantation species.
This standard log spindleles veneer peeling machine system enables good capacity and good veneer thickness tolerance compared to other spidnleless laths.
This line provides quick and automatic production and maintenance. The automatic log feeding system requires only a few operator.
Product Specification
DESCRIPTION | UNIT | BQ1813/5YC |
Length of log | mm | 1000-1300 |
Diameter of log | mm | Φ80-Φ500 |
Length of blade | mm | 1500 |
Linear speed of host machine | m/min | 50 |
Diameter of driving roller | mm | 135 |
Diameter of pressurebar roller | mm | 135 |
Power of driving roller | kw | 7.5 |
Power of pressurebar roller | kw | 7.5 |
Power of hydraulic feed | kw | 5.5 |
Total power | kw | 20.5 |
Total weight | kg | 3500 |
Overall dimensions | mm | 2900*1800*1000 |
The electrically operated Log spindleless veneer peeling machine peels high-quality veneer from hardwood and softwood. It is especially for India and Indonesia Sengon, Eucalyptus and Rubber wood and small diameter species. The modern features of this Log spindleless veneer peeling machine improve the yield and effectiveness of plantation species.
This standard log spindleles veneer peeling machine system enables good capacity and good veneer thickness tolerance compared to other spidnleless laths.
This line provides quick and automatic production and maintenance. The automatic log feeding system requires only a few operator.
Product Specification
DESCRIPTION | UNIT | BQ1813/5YC |
Length of log | mm | 1000-1300 |
Diameter of log | mm | Φ80-Φ500 |
Length of blade | mm | 1500 |
Linear speed of host machine | m/min | 50 |
Diameter of driving roller | mm | 135 |
Diameter of pressurebar roller | mm | 135 |
Power of driving roller | kw | 7.5 |
Power of pressurebar roller | kw | 7.5 |
Power of hydraulic feed | kw | 5.5 |
Total power | kw | 20.5 |
Total weight | kg | 3500 |
Overall dimensions | mm | 2900*1800*1000 |
