Film Faced Plywood Veneer Peeling Machine

Film faced plywood veneer peeling machine can peel off different sizes of wood to pieces of veneer to make artificial panel. The film faced plywood veneer peeling machine combines veneer peeling and veneer cutting in one machine. The quality and capacity of peeled plywood veneer are essential in efficiency of veneer and plywood production.

Availability:
Quantity:

Plywood Cutting Machine Factory




Plywood Cutting Machine Factory


Film Faced Plywood Machine


Film faced plywood veneer peeling machine can peel off different sizes of wood to pieces of veneer to make artificial panel. The film faced plywood veneer peeling machine combines veneer peeling and veneer cutting in one machine. The quality and capacity of peeled plywood veneer are essential in efficiency of veneer and plywood production. If you produce face veneer by not good enough Film faced plywood veneer peeling machine, you cannot keep high yield of good quality plywood.


Fuzhou Mutian produces many kinds of plywood wood veneer peeling machine, including spindleless & spindle film faced plywood veneer peeling machine, log debarker, wood veneer clipper, veneer stacker, plywood hot press machine, plywood cold press machince, wood veneer dryer and other related products.


Specification


DESCRIPTION

UNIT

BQ1813/G6SI-J

Servo

Length of log

mm

900-1400

Diameter of log

mm

30-650

Length of blade

mm

1500

Thickness of veneer

mm

0.8-4.0

Width of cut veneer

mm

500-1300

Linear speed of host machine

m/min

60m/min

Diameter of driving roller

mm

122

Diameter of pressure bar roller

mm

122

Diameter of rubber roller

mm

140

Power of pressure barroller

kw

15

Power of double roller

kw

15

Power of feeding

kw

15 (servo)

Power of shear

kw

3

Power of output conveyor

kw


1.5

Total power

kw

49.5

Total weight

kg

6500


Images


Film Faced Plywood Veneer Peeling Machine factory


Veneer Peeling Machine for Plywood Making


film faced plywood hot press machine

spindle face veneer peeling machinePlywood Board Making Machine
